The product in scope is one ODU AW 12 OR-T, which is a part of the air-to-water heat pump family Compress 5800/6800i AW (CS5800i AW/CS6800i AW) which are encased assemblies designed as a unit, using a vapor compression cycle (refrigerant R290 (Propane)) driven by an electric compressor, to provide delivery of heat according to EN 14511-1. The heat pumps turn ambient heat into energy and can be used for both cooling and heating purposes via the building's heating circuit. The heat pump system always consists of an indoor unit (IDU) and outdoor unit (ODU) connected through a water-based circuit. The accessories needed for the installation are accounted for with the ODU.

The following trade numbers and product codes are to be covered with this EPD:
12 OR-T (8-738-213-468)
Compress 5800i AW 12 OR-T (8-738-215-138)
AW 12 OR-T (8-738-215-690)
AW 12 OR-T (8-738-215-705)

The following accessories are considered in this EPD:
Cable CANbus (8-738-206-184)
INPA long (8-738-214-740)
Uponor wallDuctDWD (7-747-204-777)
ECOFLEX Anschlusspaket (7-738-336-967)
Connect-Key K 30 (7-736-603-499)

The following ODUs are identical except for the power output and related electrical consumption. The respective information and scenarios are described in sections 3.1 and 4:
AW 10 OR-T (8-738-213-467)
Compress 5800i AW 10 OR-T (8-738-215-137)
AW 10 OR-T (8-738-215-689)
AW 10 OR-T (8-738-215-704)
