Fixing systems from fischerwerke GmbH & Co. KG are made of different materials. These consist of a sleeve made of
plastic and an expansion element made of steel or plastic and be delivered in
recyclable cartons. All product components consist of new and recycled materials. The anchors differ, for example, in their specific effective length. The declaration applies to average anchors used in 3 different external thermal insulation composite systems (ETICS) with different effective lengths. For the averaging, insulation anchors from the following product range are considered. The following system-related and non-system-related insulation anchors (product names) are preferably used in ETICS facades (external thermal insulation composite system):

• TermoZ PN, CN, CNplus, CS 8, CS II,           CS 8 DT 110 V, CS II DT 110 V , 8U, SV II with accessories.
• TermoZ 6H
• TermoFix 6H-NT, B, H
• Additional plate DT 90, DT 110, DT 140
• FIF-PN, FIF-CN, FIF-CS, FIF-SV II, DIPK

The following insulation anchors are preferably used in VHF façades (curtain-type, rear-ventilated façade):

• DHK
• DHM, FDM

The anchors are used for ETICS include the following usable lengths:

• 75 - 120 mm
• 121 - 140 mm
• 141 - 160 mm

fischer anchors with a working length of more than 160 mm are covered in the EPD "ETICS Anchors" of the VDPM (Verband für Dämmsysteme, Putz und Mörtel e.V.). The results are shown for the usable length 121 - 140 mm. The results for the other usable lengths (75 - 120 mm and 141 - 160 mm) are
presented in the annexe.
